| FRAME |
ONE-FORTY LITE III; 143 STR 29"; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| SHOCK |
Marzocchi Bomber inline 143MM |
| FORK |
Marzocchi Z2; Air; 150MM; Tapered; 44mm fork offset; 29.5x2.6" max. WHS |
| BRAKE-F |
Tektro Gemini M535; 4 piston |
| BRAKE-R |
Tektro Gemini M535; 4 piston |
| ROTOR-F & R |
Tektro TR203-45; 203mm |
|
|
| CHAIN |
KMC xGlide |
| CHAINGUARD |
|
| CRANKSET |
MERIDA Expert TR II; 32 ATC |
| CRANK LENGTH |
170 mm for all sizes |
| BOTTOM BRACKET |
Samox BSA 24mm EB2401 |
| DERAILLEUR-FRONT |
|
| DERAILLEUR-REAR |
Shimano CUES U6000; GS |
| CASSETTE |
Shimano LG400; 11-50 ATC; 11 GER |
| GRIPS |
MERIDA COMP EC |
| HANDLEBAR |
MERIDA EXPERT TR II; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB |
| STEM |
MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
| STEM SIZE |
40 mm |
| HEADSET |
Acros ICR MERIDA EXTERNAL neck; Upper and lower IPS sealing |
| HUB-F |
Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB-R |
Shimano TC500-HM-B; 148x12 WHR; 32 SPH; Centerlock |
| AXLE-F |
|
| AXLE-R |
MERIDA COMP TR; including removeable lever, 6/4mm allen key |
| RIM |
MERIDA COMP TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); 29" |
| SADDLE |
MERIDA COMP SL; 25% recycled material; V-mount; incl. MERIDA minitool |
| SEAT CLAMP |
MERIDA EXPERT |
| SEATPOST |
MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XSHORT/SHORT: 150 SPT - MID: 170 SPT - LONG: 200 SPT - XLONG: 230 SPT |
| SHIFTER-FRONT |
|
| SHIFTER-REAR |
Shimano CUES U6000 |
| SPOKES |
Black stainless |
| TIRE-F |
Kenda Regolith; 29x2.4"; wire |
| TIRE-R |
Kenda Regolith; 29x2.4"; wire |
